Description
Kubota M7060 Specs
Engine:
| engine | Kubota V3307-CF-TE4 turbocharged diesel 4-cylinder liquid-cooled inline 203 ci [3.3 L] |
| Bore/Stroke: | 3.7×4.7 inches [94 x 119 mm] |
| Emissions: | Tier IV |
| Emission control: | exhaust gas recirculation (EGR) |
| Fuel system: | common rail direct injection |
| Rated RPM: | 2400 |
| Starter: | electric |
| Starter volts: | 12 |
capacity
| ROPS Fuel: | 18.5 gal [70.0 L] |
| Cab Fuel: | 23.8 gal [90.1 L] |
3 Point Hitch
| Rear Type: | II/I |
| Control: | position control and top-link draft sensing |
| Rear lift (at 24″/610mm): | 3307 lbs [1500 kg] |
| Rear Arms: | telescopic lower link ends |
Kubota M7060 Power
| Engine (net): | 71 hp [52.9 kW] |
| PTO (claimed): | 64 hp [47.7 kW] |
Mechanical
| Chassis: | 4×2 2WD |
| 4×4 MFWD 4WD | |
| Steering: | hydrostatic power |
| Brakes: | wet disc |
| hydraulic wet disc (12-speed) | |
| Cab: | Two-post foldable ROPS. Optional Ultra Grand Cab with air-conditioning. Optional air-ride seat and AM/FM/CD/MP3 sound system. |
